Mechanical
touch-monitor-contour-drawing
LCD Display
aruze-gaming-logo
23"
509.184mm x 286.4mm
1920*1080
0.2928mm
16.7M
16：9
1000：1
250cd/cm²
LED Lighting Bar Type
89/89/89/89
Product Images
Panel Size
Active Area
Number Of Pixels
Pixels Pitch
Display Colors
Scale Ratio
C/R
Brightness
Back-Light
Viewing Angle Range
TOM2302E00-V8

536mm x 341.3mm x 39mm

4kg



Product Model
Product Dimension
Net Weight
Package Dimension
Gross Weight

Aruze Gaming X-Station

Super Big Wheel/Lucky Roulette/

Shoot to Win Craps-Lucky Roll

23" Monitor

aruze-gaming-shoot-to-win-craps-lucky-roll-table-machine
The same size as the prototype, dedicated to upgrading and replacing the touch monitor on the Aruze Gaming X-Station Super Big Wheel/Lucky Roulette/Shoot to Win Craps-Lucky Roll Tables model

  • Monitor P/N: XXXXXXX
  • Monitor Model: W23UDZ21-3D
  • TMD Model: TOM2302E00-V8

aruze-gaming-shoot-to-win-craps-lucky-roll-touch-monitor-tot2152epc-v1-0
aruze-gaming-shoot-to-win-craps-lucky-roll-touch-monitor-tot2152epc-v1-2
aruze-gaming-shoot-to-win-craps-lucky-roll-touch-monitor-tot2152epc-v1-1
aruze-gaming-shoot-to-win-craps-lucky-roll-touch-monitor-tot2152epc-v1-3
aruze-gaming-shoot-to-win-craps-lucky-roll-touch-monitor-tot2152epc-v1-4
aruze-gaming-shoot-to-win-craps-lucky-roll-touch-monitor-tot2152epc-v1-5
Environmental
Operating：0°C~45°C

 Storage：-20°C-55°C



Operating：10%-80%RH, 40"C
Storage：10%-80%RH, 40°C

Temperature




Humidity

aruze-gaming-roulette-touch-monitor-dimensions-tot2152epc-v1

Dimensional Drawing

Quality Assurance
Products are assembled in a dust-free workshop,all accessories are made of raw materials, no second hand materials.
